Operating Weight:1880kg
Bucket Capacity:0.04m³
Track Width:230mm| Operation weight | 1880kg | Wheelbase | 1100mm |
| Bucket Capacity | 0.04m3. | Track connection length on ground |
1670mm |
| Working device form | backhoe | Platform ground clearance |
400mm |
| Power | 14.6K W/20 hp | Chassis width | 1100mm |
| Max. digging radius | 3470mm | Track width | 230mm |
| Max.excavation depth | 2200mm | Machine length | 2170mm |
| Max.excavation height | 3275mm | Total height | 2600mm |
| Max. unloading height | 2400mm | radius of gyration | 1550mm |
| Multi-way valve | Japan | hydraulic pump | Italy |
| Overall size | 21 70mm*1100mm*2600mm | ||
