Operating Weight:1450kg
Bucket Capacity:0.035m³
Track Width:180mm| Operation weight | 1450kg | Wheelbase | Cope 820mm |
| Bucket Capacity | 0.035m3 | Track connection length on ground |
1300mm |
| Working device form | backhoe | Platform ground clearance |
400mm |
| Power | 14KW/20 hp | Chassis width | 1 100mm |
| Max. digging radius | 2400mm | Track width | 180mm |
| Max.excavation depth | 1850mm | Machine length | 2400mm |
| Max. unloading height | 2740mm | Total height | 2300mm |
| Max. unloading height | 2400mm | radius of gyration | 1 200mm |
| Multi- way valve | Japan | hydraulic pump | Italy |
| Overall size | 2200mm*1100mm* 2200mm | ||
